Custom Silicon Carbide Gear Pump Bearing
| 원래 장소 | 중국 |
|---|---|
| 브랜드 이름 | CSQ |
| 인증 | FDA,REACH,ROHS,ISO9001,ISO14001,ISO45001 |
| 모델 번호 | 맞춤형 제품 |
| 최소 주문 수량 | 20-50 PC |
| 가격 | negotiable |
| 포장 세부 사항 | 폼+카톤 박스 |
| 배달 시간 | 20-45 일 |
| 지불 조건 | t/t |
| 공급 능력 | 한 달에 2000pc |
무료샘플과 쿠폰을 위해 나와 연락하세요.
왓츠앱:0086 18588475571
위챗: 0086 18588475571
스카이프: sales10@aixton.com
만약 당신이 어떠한 관심도 가지면, 우리가 24 시간 온라인 도움말을 제공합니다.
x제품 상세 정보
| 이름 | 맞춤형 세라믹 슬라이딩 베어링 | 범주 | 세라믹 펌프 베어링 |
|---|---|---|---|
| 재료 | 압력이없는 소결 실리콘 탄화물/지르코니아 | 크기 | 도면에 따라 맞춤화되었습니다 |
| 사용 | 기어 펌프 | 패키지 | 폼+카톤 박스 |
| 예어 | 기어 펌프 베어링 | 유형 | 중요한 전송 부분 |
| 강조하다 | Silicon Carbide gear pump bearing,High temperature resistant ceramic bearing,1650℃ resistant sliding bearing |
||
제품 설명
Custom Silicon Carbide Gear Pump Bearing for Industrial Use
Customized Silicon Carbide or Zirconia Sliding Bearing for Gear Pump
Product Introduction
Silicon Carbide (SiC) gear pump bearings are manufactured from high-performance reaction-bonded or sintered silicon carbide, offering exceptional corrosion resistance, wear resistance, and thermal stability. Designed for gear pumps in extreme operating conditions, they significantly extend service life and reduce maintenance costs.
Gear pumps transfer fluid via rotating meshing gears, while gear pump bearings are critical components supporting the gear shafts, directly affecting smooth operation, lifespan, and efficiency. Their roles include:
- Shaft Support - Withstand radial/axial loads to ensure precise gear alignment
- Friction Reduction - Minimize wear at high speeds for energy efficiency
- Chemical Resistance - Especially in chemical pumps (e.g., silicon carbide bearings resist acids/alkalis)
Bearing failure can cause gear misalignment, leakage, or seizure, making material (e.g., metal, ceramic) and design vital for pump reliability. Bearings act as the "joints" of gear pumps, synergizing with gears to define performance.
Key Features
Key properties of pressureless sintered silicon carbide:
| Max Temperature | up to 1650℃ |
| Density | 3.15-3.18 g/cm³ |
| Thermal Expansion | 4.0 (10-6/℃) |
| Thermal Conductivity | 120 W/m°K |
| Hardness | 2800 HV5 |
| Elastic Modulus | 410GPa |
| Chemical Stability | Superior resistance to acid and alkali corrosion (including hydrofluoric acid) |
Parameter Table
| Parameter | Description |
|---|---|
| Material | Ceramic: SSIC, Si3N4, ZrO2 |
| Corrosion resistance | Excellent |
| Friction | Lower than steel |
| Wear resistance | Excellent |
| Temperature resistance | High |
| Strength | Higher than steel |
| Durability | Excellent |
| Weight | Lighter than steel |
| Precision | High |
| Biocompatibility | Some ceramic materials are biocompatible |
Our Manufacturing Capabilities
We have three factories in China, capable of meeting different customer needs, equipped with advanced pressing, sintering and processing machines.
Why Choose Us
According to structure differences, gear pumps can be divided into external gear pumps and internal gear pumps. Our company has ample production experience with both types of gear pump sliding bearings in silicon carbide material. We have supplied SSiC sliding bearings to Germany's Witte for many years.
Frequently Asked Questions
Q: Who are we?
A: We are a factory in Beijing, China with over 40 years of experience producing ceramic bearings. We have established cooperative relations with many domestic and international companies.
Q: How do we guarantee quality?
A: We produce samples before mass production and strictly follow customer requirements. After production, we use inspection equipment for precise quality control. Our packaging includes foam and carton for double protection.
Q: What products do we offer?
A: Ceramic deep groove ball bearings, ceramic angular contact ball bearings, hybrid ceramic ball bearings, ceramic linear bearings, and various ceramic balls.
Q: Why choose us over other suppliers?
A: As an integrated company with three factories and modern production/inspection equipment, we offer better delivery times and product quality.
Q: What services do we provide?
A: We offer high-quality products and customized services tailored to user needs, including sample provision for customer confirmation.
Welcome Your Enquiry
We supply high-quality bearings and related technical services. As a professional bearing company integrating R&D, production, sales, and service, we carefully manufacture each bearing using premium materials.
We prioritize customer needs, striving to provide quality products and after-sales service to create value and become your trusted partner. We welcome discussions about potential cooperation!
